Electron is a small-lift launch vehicle built by Rocket Lab to give small satellites dedicated rides to orbit rather than rideshare slots on larger rockets. Just 18 meters tall and 1.2 meters across, it carries up to 300 kilograms to low Earth orbit and has flown 91 times since May 2017, including nine suborbital HASTE missions, making it the most-launched small orbital rocket in the world and the second most active US launcher after SpaceX's Falcon 9.[1][2]
Electron introduced two firsts in orbital rocketry: an airframe and tanks made almost entirely of carbon fiber composite, and Rutherford engines whose propellant pumps are driven by battery-powered electric motors instead of gas turbines. The rocket launches from a private site on New Zealand's Mahia Peninsula and from Wallops Island, Virginia, and has deployed more than 260 satellites for commercial constellations, NASA, and defense customers.[1][3]
Design and specifications
| Parameter | Electron |
|---|---|
| Height | 18 m |
| Diameter | 1.2 m |
| Liftoff mass | 13,000 kg |
| First stage engines | 9 Rutherford (kerosene/liquid oxygen, electric pumps) |
| Second stage engine | 1 vacuum-optimized Rutherford |
| Third stage | Kick Stage with restartable Curie engine |
| Payload to low Earth orbit | 300 kg |
| Payload to Sun-synchronous orbit | About 200 kg |
| Structure | Carbon fiber composite |
The Rutherford engine is largely 3D printed, with combustion chambers, injectors, pumps, and valves produced additively; Rocket Lab was the first company to fly electric-pump-fed engines to orbit. Nine Rutherfords power the first stage, producing about 234 kN of combined thrust in vacuum, and a single vacuum-optimized version with a larger nozzle (25.8 kN) powers the second stage. Batteries that drain during ascent are jettisoned in flight to save mass.[1]
Kick Stage and Photon
Most missions include a third element, the Kick Stage, powered by the restartable Curie engine. It circularizes orbits, deploys multiple payloads into different planes, and then deorbits itself to limit debris. Rocket Lab evolved the Kick Stage into Photon, a full satellite bus that can host payloads or fly interplanetary trajectories: a Photon upper stage sent NASA's CAPSTONE cubesat toward the Moon in June 2022, the first deep space mission launched from New Zealand.[1]
Launch record
Electron's debut on May 25, 2017, nicknamed "It's a Test," was terminated by range safety because of a ground telemetry fault; the second flight, "Still Testing," reached orbit on January 21, 2018. Through the end of June 2026 the vehicle had flown 91 times with four failures (the 2017 debut plus one each in 2020, 2021, and 2023), and none since September 2023.[1][2]
| Milestone | Date | Mission |
|---|---|---|
| First launch attempt | May 25, 2017 | "It's a Test" |
| First orbital success | January 21, 2018 | "Still Testing" |
| First booster splashdown recovery | November 20, 2020 | "Return to Sender" |
| First lunar mission (CAPSTONE) | June 28, 2022 | "CAPSTONE" |
| First Wallops, Virginia launch | January 24, 2023 | "Virginia Is For Launch Lovers" |
| First HASTE suborbital flight | June 18, 2023 | For Leidos |
| First reflight of a used Rutherford engine | August 2023 | Flight 40 |
Cadence has climbed nearly every year, and 2026 is the busiest yet: the mission scheduled for June 30, 2026 (an iQPS radar imaging satellite flight named "The Grain Goddess Provides," scrubbed by a last-second abort and recycled to July) was to be Electron's 92nd overall and 13th of the year. In June 2026 Rocket Lab also set a responsive-launch record for the US Space Force's VICTUS HAZE exercise, going from notice to liftoff in 16 hours and 42 minutes.[2][3][4]
Booster recovery program
Rocket Lab pursued first stage reuse in phases. Flights beginning with "Return to Sender" in November 2020 demonstrated guided reentry and parachute splashdown, and on May 2, 2022, a helicopter briefly snagged a descending booster in midair on the "There And Back Again" mission before releasing it into the ocean. The company concluded that marine recovery was simpler and nearly as effective, dropped the helicopter approach, and refurbished recovered hardware; a previously flown Rutherford engine returned to flight in August 2023 after passing full-duration requalification tests.[1][5]
Full Electron reflight was never made routine. Rocket Lab has since concentrated its reusability investment on Neutron, its medium-lift rocket with a first flight targeted for no earlier than late 2026, while Electron continues to fly in expendable configuration on most missions. The recovery campaign nonetheless supplied the company's engineers with flight-proven data on reusable rocket operations that fed directly into Neutron's design.[1][5]
HASTE
The Hypersonic Accelerator Suborbital Test Electron (HASTE) is a modified Electron that lofts up to 700 kilograms on suborbital trajectories for hypersonics research, primarily for US defense agencies and their contractors. HASTE first flew on June 18, 2023 from Virginia and had completed nine missions by mid-2026, giving the Pentagon a commercial testbed for reentry vehicles, scramjet experiments, and materials at a fraction of traditional program costs.[1][2]
Launch sites and cadence
Rocket Lab operates two pads at Launch Complex 1 on the Mahia Peninsula, the world's first private orbital launch site, licensed for a high annual flight rate over the Pacific. Launch Complex 2 at the Mid-Atlantic Regional Spaceport on Wallops Island, Virginia, entered service in January 2023 and hosts US government and HASTE missions. Operating from both hemispheres lets the company serve nearly any inclination and schedule dedicated launches within days of customer need, the core of Electron's business case against rideshare alternatives.[1][3]
